    Buy cheap SJK-7U 8MHz SMD3225 Quartz Crystal Unit from wholesalers

    Buy cheap SJK-7U 8MHz SMD3225 Quartz Crystal Unit from wholesalers
    • Buy cheap SJK-7U 8MHz SMD3225 Quartz Crystal Unit from wholesalers
    • Buy cheap SJK-7U 8MHz SMD3225 Quartz Crystal Unit from wholesalers

    SJK-7U 8MHz SMD3225 Quartz Crystal Unit

    Ask Lasest Price
    Brand Name : SJK
    Model Number : SJK 7U SMD3225 8MHz Quartz Crystal
    Certification : SGS, RoHS, REACH
    Price : Negotiate
    Payment Terms : T/T
    Supply Ability : 30K pcs per Month
    Delivery Time : 2~4weeks
    • Product Details
    • Company Profile

    SJK-7U 8MHz SMD3225 Quartz Crystal Unit


    SJK-7U 8MHz SMD3225 Quartz Crystal Unit High Precision and Stability appication for indusrtial control


    Features:

    • Reliable seam sealed ceramic package.
    • Wide operating temperature range.
    • Superior performance and stringent reliability in harsh environment.
    • Application: MCU, Industrial Control, Factory Automation, IoT, ABS and sensor modules, etc.
    • Compact size.
    • RoHS Compliant / Pb Free.

    Specifications:


    ItemSJK-7U SMD3225 8MHz Quartz Crystal
    Nominal Frequency8MHz
    Overtone OrderAT/Fundamental
    Frequency Tolerance (@25ºC)±10ppm
    Load Capacitance12pF
    Drive Level100μW Typical
    Operating Temperature-40°C to +85°C
    Storage Temperature-55°C to +125°C
    Frequency Stability Over Operating Temperature Characteristics±30ppm
    Equivalent Series Resistance(ESR)150Ω max.
    Shunt Capacitance2pF max.
    Aging @25°C 1st year (Max)±3ppm/year
    Package Size(L×W×H)(mm)3.2×2.5×0.7

    Dimensions and Soldering Plattern:

    SJK-7U 8MHz SMD3225 Quartz Crystal Unit
